2026 PAM SUPER 40

GENERAL OPERATION

a) Baling

There are two pairs of sensors placed in the hopper of the baler for controlling the feeding operation located at the

bottom. When the sensors of the bottom are activated the baler starts the compaction cycle, when those sensors are

not activated the baler is in stand-by waiting for more material.

The cycle starts when the ram moves forward introducing (compacting) the material inside the chamber and going

back to the initial position. For making a bale the machine needs various cycles, depending on the desired bale

density.

GENERAL FEATURES

 Low Energy Consumption

 Automatic shut down the machine / sleeping mode if no materials are feeding. ( This time frame can be

changeable from the operator interface touch screen.

 Safe and easy usage.

 Counter of number of bale made in a day and life of the baler also number of hours operation in life of the

baler.

 Long life Low Noise (60 dB).

 Bale table / Bale exit tray.

 Two shaft pet perforator will be fitted in the top of hopper of the baler. If baler press the carton or plastic Petperforator comes out automatically from the hopper and if baler press PET , that time pet perforator moves

inside the hopper to perforate the pet before falling in the baler hopper.

 Reliable Constriction.

 Availability of a set of quickly wearing parts during the warranty period and after production at least 10 years.

 Touch Screen 7” PLC Control

 3 set Hopper sensor to sense the level of the hopper feed.

 Continuous Feed Baler

 Automatic Wire Tie

 Machine comes with bale counter and info feed to PLC how much bale has been created

 Live pressure shows on the PLC

 Colour coding system for different materials in the operation system

 Pre define pressure settings system for different materials

 Hour counter, overloading, emergency stop, door open warning system are available

 A set of maintenance tools will be provided for the machine

 Automation package in feed management system

 Body shear blade/adjustable cutting knives in replaceable

 Hopper view door

 Free-standing operator centre

 Automation switch-off when filling is not in process

 Compaction chamber floor Replaceable HARDOX 450 plates.

 Push plate line and top of the push plate made with replicable HARDOX 450

 Machine automation troubleshoot is possible through laptop over internet.

 Special electronic security device for inspection and access door. (Magnetic coded two way device ).

 The loading hopper is equipped with service door.

 Replacable moving and fixed knife.

 Emergency shutdown of equipment when the level falls and the oil temperature rises.
